Product Details
- Size: 2134mm*420mm*420mm
- Place of Origin: Shandong,China
- Brand Name: Fusai
- Model Number: FSA12GNR2
- Weight: 356.000 kg
- :
- :
- :
- :
- :
German (BPW) type axle
1) Capacity:12T/14T/16T
2) brake size:420*180/420*200
3) axle tube size:150*150*12/150*150*14/150*150*16/150*150*18
American type axle-Drum type
1) Capacity:12T/13T/16T
2) Axle beam (mm):Φ127*16/150*150*12/150*150*16
3) Brake (mm):420*180/420*220
4) Track (mm):1820/1840
5) Bearings :HM518445/10/HM518445/10
6) Center distance of brake chamber (mm):368/388/354
7) Stud :10*M22*1.5ISO/10*M20*1.5JIS
8) P.C.D (mm)*ΦH (mm):335*Φ281/285.75*Φ221/285*Φ221
9) Total length (mm):2165/2185
10) Weight (kg):361/350/420
1) Capacity:12T/14T/16T
2) brake size:420*180/420*200
3) axle tube size:150*150*12/150*150*14/150*150*16/150*150*18
American type axle-Drum type
1) Capacity:12T/13T/16T
2) Axle beam (mm):Φ127*16/150*150*12/150*150*16
3) Brake (mm):420*180/420*220
4) Track (mm):1820/1840
5) Bearings :HM518445/10/HM518445/10
6) Center distance of brake chamber (mm):368/388/354
7) Stud :10*M22*1.5ISO/10*M20*1.5JIS
8) P.C.D (mm)*ΦH (mm):335*Φ281/285.75*Φ221/285*Φ221
9) Total length (mm):2165/2185
10) Weight (kg):361/350/420
- Size: 2134mm*420mm*420mm
- Place of Origin: Shandong,China
- Brand Name: Fusai
- Model Number: FSA12GNR2
- Weight: 356.000 kg
- :
- :
- :
- :
- :
